WARNING: Only used a high pressure cleaner approved by BMW! Only instructed persons aged over 16 years may work using a high pressure cleaner.
Check the high pressure cleaner and electrical wiring for visible damage.
Only use at a suitable location.
IMPORTANT:
Pay attention to following hazard warnings:
- Danger of injury due to water jet
- Contact with hazardous substances in spray
- Risk of skidding on wet floor
- Risk of stumbling due to hoses and cables
- Comply WITH NOTES AND INSTRUCTIONS ON HANDLING CLEANING AGENTS !
- Risk of scalding when cleaning with hot water.
- On electric or hybrid cars, the safety instructions for handling with hybrid cars are to be complied with.
WARNING: The following personal protective equipment is to be used:
- Safety goggles/face guard
- Suitable gloves
- Apron
- Rubber boots
- Ear protectors
- Safety shoes
IMPORTANT:
Notes on washing a vehicle with a high pressure cleaner:
- Do not wash directly on gaskets and control units during engine washes.
- A minimum distance of 30 cm must be adhered to for tires and tire valves.
- A minimum distance of 30 cm must be adhered to for the soft top and painted parts.
- Do not use if engine is still hot.
- Do not exceed maximum water temperature of 60 degrees.
- Do not spray directly onto cameras/sensors.
- On electric or hybrid cars do not wash on high-voltage components.
BMW X3 Service & Repair Manual > Propeller shaft assembly: Removing and installing/replacing front centring mount for propeller shaft
Special tools required:
00 5 500
11 1 310
11 2 030
Necessary preliminary tasks:
Remove PROPELLER SHAFT.
Completely fill centring bore hole (1) with viscous grease.
Drive special tool 11 1 310 with a plastic hammer into centring bore hole.
The centring bearing (1) is forced ou ...
